The main engine of the Tianwang Security Electric Fence Energizer is small in size,simple in appearance and easy to install. There is a pulse generator inside the controller, which generates a high-voltage pulseby controlling the pulse generator and periodically outputs it. The high-voltage pulse generator is transmitted to a closed area surrounded by front-end wires with front-end conductive cables, which can effectively block animal activities inside and outside the area; When inside the area, external animals will be hit by a high pressure when they are close to the front guide cable. After the animals are hit, they will form conditioned reflex and will only move inside the area. When animals outside the area want to invade, they will be blocked by the guide cable and hit by high pressure, thus effectively preventing possible dangers outside the area.
Power supply method
1. Adapter power supply
Connect to the 220V ranch system by using the equipped adapter
2. Solar panel & lead-acid battery power supply
Solar panels and lead-acid batteries are used for matching power supply. Solar panels can provide energy for the energy controller during the day. Colleagues can also supply power to the battery and charge the battery at the same time. At night, the battery can use the electricity accumulated during the day to supply power to the energy controller.
What other accessories do electronic fences need in addition to electronic fencing energy enhancers?
1.Self-tapping electric fence insulator: mainly installed on wooden pillars, supporting and fixing operations
2. Flat head ranch insulator: it is mainly installed on the pole with hole position to support and fix it
3. Self-tapping electric fence insulator: the insulator used at the corner of the pasture
4. Two-way insulator: The two-way insulator used at the gate of the ranch is used together with the
handle and spring.
5. Handle: the insulation handle of the ranch door, which is used together with the bidirectional insulator and spring.
6. Spring: ranch door spring, used together with bidirectional insulator and handle.
7. Conductive rope: special conductive rope for pasture
8. Lightning Protector: Ranch capability controller lightning protection equipment
9. Grounding pile: ground plug of ranch capability controller and lightning Protector 10 solar power supply: farm capacity controller solar power supply
11. Waterproof tank: equipment waterproof tank, stainless steel material
How to install the Electric Fence Energizer Box?
1.Fix the main machine of the Electric Fencing Energizer.If it is installed outdoors, it needs to be installed in the waterproof box.
2. The terminal of the Farm Fence Voltage Energizer has two terminals, red and black, or two terminals, red and black. The red terminal is the high voltage pulse output terminal and the black terminal is the grounding terminal. The right side cover of the device has a 3.5mm audio output speaker interface. The P6 host can press the key on the equipment or use the remote control cloth to remove the defense.
3. Front-end wooden stake installation insulator,spring, insulation handle and other accessories.
The front-end fence of electronic fence consists of terminal Rod, terminal Rod insulator, terminal Rod rainproof cap, fixed clip, bearing Rod, bearing Rod insulator, bearing Rod rainproof cap, PV over-wire rod, PV Rod insulator, PV Rod rainproof cap, tighter, alloy wire, high-voltage insulated wire, warning sign, Lightning protector, U-shaped hanging line seat, wire connector, sound and light alarm, etc.
Inspect the setting of electronic fence installation location:
1.it is required that the electronic fence has no conflict with the wires and pipelines in the underground and air directions;
2.there is no sundries in the area near the fence;
3.whether there is a strong interference source (such as high frequency equipment such as launch pad) near the installation site of the fence device, and if so, the signal line must be shielded twisted pair in the construction drawing.
